Features and benefits:
- Fire-safe to ISO 10497 and API 607
- Mirror-finished solid stainless ball
- Fine-grained PTFE seats
- Cavity Pressure Relief mechanism
- Blowout-proof stem
- High integrity stem sealing – Belleville springs compensate for wear and thermal expansions
- Antistatic feature
- Actuator-mounting flange conforms to ISO 5211
- SIL3 Safety Integrity Level for Automated Valves
Versatile Solutions:
- Single, two and three piece constructions
- Full-bore and regular-bore designs
- Soft and metal-seated
- Offered in carbon steel, stainless steel and duplex stainless steels
- Screwed, socket-weld and flanged ends
- ASME classes up to 2500
- Variety of actuation options
Size range(s): NPS 2 – 56 (DN 50 – 1400) Pressure rating: ASME Classes 150 – 1500 Standard : API 6D
