Features and benefits:
- A compact but extremely sturdy design for high pressure- temperature service.
- Available types: Stop, Stop check, Needle, Flow control.
- Available with bolted or welded bonnet.
- Packing rings are precompressed to 4000 psi to provide a high integrity seal.
- Repairable 2-piece stem drive.
- Available with double packing, leak-off connection and live-loading.
Size range(s):
NPS 1/4 – 2 (DN 8 – 50)Pressure rating:ASME Classes 150 – 1500Standard connections :Threaded, socket weld, flanged
